Equipment

Thermop DFS
Thermo DFS



High-resolution mass analyzer (GC-)MS equipped with electron- and chemical-ionization (EI and CI), direct chemical ionization (DCI), gas chromatograph (GC), and autosampler incl. headspace sampling and automatic derivatization. Suited for the analysis of small and volatile molecules with rather low polarity that can be evaporated without decomposition.

Instrument description file:

InstrDescr_(GC-)HR-MS_DFS (PDF, 74 KB)



Bruker timsTOF Pro
Bruker timsTOF Pro

High-resolution ion mobility QTOF UHPLC-MS(/MS) fitted optionally with electrospray ionization, atmospheric pressure chemical ionization, and atmospheric photoionization sources (ESI, APCI or APPI). This system with a resolution up to 70’000, a mass accuracy ≤ 2 ppm and an extended mass range (m/z 50-20'000) allows MS/MS experiments, calculation of the collision cross section of ions (CSS), and is on-line coupled to a Vanquish UHPLC system (up to 1500 bar).
Suited for structure elucidation and quantification of labile compounds in complex samples (e.g. polar compounds, metal complexes, biopolymers) biological extracts). Separation of ions with the same mass such as structural isomers is possible.

Instrument description file:

InstrDescr_LC-HR-IM-MS_timsTOFPro (PDF, 114 KB)



Thermo QExactive

High-resolution Orbitrap HPLC-MS(/MS) instrument fitted with an electrospray- or atmospheric pressure ion source (ESI or APCI). This system has a resolution up to 140’000, a mass accuracy ≤ 2 ppm, an extended mass range (m/z 50-6000) and is on-line coupled to an Ultimate 3000 UHPLC system (up to 1000 bar).
Suited for structure elucidation and quantification of labile compounds in complex samples (e.g. polar compounds, metal complexes, and biopolymers) and complex biological extracts.

Instrument description file:



AutoflexSpeed_Maldi
Bruker AutoflexSpeed

Maldi-TOF instrument equipped with Smartbeam laser and stainless steel targets. A thin-layer chromatography plate adapter allows Maldi imaging of TLC plates. Suited for the analysis of polyaromatic hydrocarbones, dendrimers, peptides, proteins, polymer, and metal complexes of higher MR. Mass accuracy ≤ 5 ppm.

Instrument description file:



ICP_MS
Agilent 8800 ICP-MS

Inductively coupled plasma triple quadrupole mass spectrometer equipped with a standard micro-flow sprayer or an apex-IR nebulizer.
Suited quantification of elements in ultra-trace level in organic, inorganic, and biological samples.

Instrument description file:

InstrDescr_ICP-MS_Agilent8800 (PDF, 58 KB)



Open access:

Waters Synapt G2
Waters Synapt G2

High-resolution QTOF UHPLC-MS(/MS) fitted with an electrospray ion source (ESI). This system has a resolution up to 40’000, a mass accuracy ≤ 2 ppm, and is on-line coupled to a Waters UPLC.
Suited for e.g. reaction control and product characterization incl. determination of relative amounts, calculation of chemical formulae of mid-polar to polar small and large molecules found in complex and labile samples.

Instrument description file:

InstrDescr_LC-MS_OpenAccess_SynaptG2 (PDF, 73 KB)





Thermo ISQ GC/MS (Praktikum)
Thermo ISQ GC/MS (Praktikum)

Operation Guide ISQ (PDF, 3 MB)

Thermo Scientific ISQ GC/MS equipped with a Trace 1300 GC, split/splitless injector, a Zebron ZB-5MS capillary column, an electron ionization source at 70 eV, and a single stage quadrupole mass analyzer.
Suited for the analysis of mixture containing volatile compounds.

Instrument description file:

InstrDescr_GC-MS_ISQ (PDF, 66 KB)





No longer in use:

Bruker maXis
Bruker maXis

High-resolution QTOF HPLC-MS(/MS) fitted optionally with an electrospray- or atmospheric pressure ion source (ESI or APCI). This system with a resolution up to 40’000 and a mass accuracy ≤ 2 ppm allows MS/MS experiments, measurements in an extended mass range (m/z 50-20'000) and is on-line coupled to a Waters UPLC.
Suited for investigation incl. calculation of chemical formulae of complex and labile samples (e.g. metal complexes), mid-polar to polar small and large molecules, biopolymers and complex biological extracts.

Instrument description file:

InstrDescr_(LC-)HR-MS_maXis (PDF, 32 KB)
